1. Telescopic boom for extended reach and higher lift height.
2. 2-ton rated load with strong and reliable performance.
3. Compact design suitable for various working conditions.
1. More flexible and efficient than standard wheel loaders.
2. High stability with excellent cost performance.
Engine
| (1) Brand/Model: | YUNNEI YN33GBZ | |
| (2) Type: | In-line arrangement, water-cooled, four cylinder, turbocharged diesel engine | |
| (3) Rated Power: | 65KW | |
| (4) Optional Model: | CUMMINS 4BT3.9-C100 | |
| EURO5 55KW CHANGCHAI | ||
| EPA4/EURO5 KOHLER | ||
| EPA4 CUMMINS | ||
Overall Dimensions
| (1) Overall Length: | 6500mm | |
| (2) Overall Width: | 2000mm | |
| (3) Overall Height: | 2860mm | |
| (4) Max. Discharge height: | 4400mm | |
| (5) Min. Discharge height: | 3400mm | |
Transmission System：Gearbox + Hydraulic converter + Drive shaft + Hub reduction axle
Bucket
| (1) Capacity: | 1m³ | |
| (2) Width: | 2000mm | |
| (3) Type: | Heavy-duty bolt on teeth | |
| (4) Max. Load: | 2000kg including bucket or attachment | |
Operating Specifications
| (1) Steering System: | Articulated hydraulic steering | |
| (2) Driving System: | Four wheel drive | |
| (3) Hydraulic quick release | Yes | |
| (4) Mechanical pilot joystick | Yes | |
| (5) Steady rise | Yes | |
| Brake System | ||
| (1) Service Brake: | Four wheel disc brake | |
| (2) Parking Brake: | Disc brake | |
| Tyre | ||
| (1) Model: | 16/70-20 Herringbone Tyre | |
| (2) Size: | Width: 380mm | |
| Diameter: 1075mm | ||
| Wheel base: 2550mm | ||
| Track: 1600mm | ||
| System pressure: | 20Mpa | |
| Weight: | 5500KG | |
The TL2000 is a highly efficient telescopic wheel loader designed for use in medium-sized projects. Its versatility makes it the ideal machine for completing tasks on an urban pipeline project, loading and unloading at a medium-sized trucking facility and transporting materials within a short distance from a mining location.
It is equipped with a 65KW high-power engine, which offers abundant and stable power output, quick response, and is capable of easily handling high-intensity operation scenarios such as heavy-duty loading and frequent start-stop. The engine also balances efficiency and reliability, ensuring the performance of the operation while effectively controlling fuel consumption, helping users reduce long-term operating costs.
The telescopic wheel loader is designed with the operator in mind and provides comfort and protection from the damaging effects of vibration by utilizing an advanced boom shock absorber and oversized heavy-duty tires to absorb the extreme vibrations associated with rough terrain. This allows the operator to maintain maximum comfort during extended periods of operation.
